Summary of Contents for Red Jacket 344-001-5
- Page 1 Manual No: A042-078 ● Revision: E 4” AG Pump Service Kit Part No. 344-001-5 Installation Guide...
- Page 2 For the parts return procedure, please follow the instructions in the “General Returned Goods Policy” pages of the “Policies and Literature” section of the Veeder-Root North American Red Jacket Mechanical Products Price Book. Veeder-Root will not accept any return product without a Return Goods Authorization (RGA) number clearly printed on the outside of the package.
-
Page 3: Table Of Contents
Table of Contents Introduction Safety Precautions ......................1 Warnings and Instructions ....................2 Important Safety Information ..................2 Preliminary Precautions....................2 Requirements For Use .....................3 Operating Precautions....................3 Replacing The Quad Seal Removing the Pump ......................4 Replacing the Functional Element Adjusting the Functional Element ..................9 To Adjust the Relief Pressure...................9 Functional Element Parts List.................11 Figures... -
Page 4: Safety Precautions
Introduction This manual contains installation, operation, and service information for the Red Jacket 4-inch Standard Submersible Petroleum and AG pump. Safety Precautions The following safety symbols are used throughout this manual to alert you to important safety hazards and precautions. -
Page 5: Warnings And Instructions
4” Standard Pump Installation, Operation & Service Manual Warnings and Instructions Warnings and Instructions IMPORTANT SAFETY INFORMATION This section introduces the hazards and safety precautions associated with installing, inspecting, maintaining or servicing this product. Before performing any task on this product, read this safety information and the applicable sections in this manual, where additional hazards and safety precautions for your task will be found. -
Page 6: Requirements For Use
4” Standard Pump Installation, Operation & Service Manual Warnings and Instructions FIRE HAZARD! Do NOT use power tools (Class I Division I and Class I Division II) during the installation or maintenance of equipment. Sparking could ignite fuel or vapors, resulting in fire. CHEMICAL EXPOSURE HAZARD! Wear appropriate safety equipment during installation or maintenance of equipment. -
Page 7: Replacing The Quad Seal
Replacing The Quad Seal Removing the Pump DANGER! Always disconnect, lock out, and tag the power before starting to service the pump. When servicing unit use non-sparking tools and use caution when removing or installing equipment to avoid generating a spark. 1. - Page 8 4” Standard Pump Installation, Operation & Service Manual Removing the Pump 4. Swing the electrical connector aside. 5. If a siphon system is in place, disconnect the siphon tubing. If ball valves are installed, close them. 6. Remove the two lock-down bolts. To relieve pressure, rock the pump to allow excess pressure to flow into the tank or back out pressure adjustment screw (see Figure 6).
-
Page 9: Figure 3. Locating 7" Packer O-Ring And Quad Seal
4” Standard Pump Installation, Operation & Service Manual Removing the Pump Functional Element Leak Detector Port Plug (or Line Leak Detector) Packer Functional Element Leak Detector Port Packer Plug (or Line Leak Detector) 7” O-Ring 7” O-Ring Packer Seal Packer Seal Quad Seal Manifold Manifold... - Page 10 4” Standard Pump Installation, Operation & Service Manual Removing the Pump 17. Swing the electrical connector into position. 18. Torque the electrical connector bolt to 25 – 50 ft-lb (34 – 68 N•m). 19. Torque the conduit box bolts to 30 – 45 ft-lb (40 – 61 N•m). NOTE: suggested tools (non-sparking) include a 3/4'' wrench, pipe wrench, 1/4”...
-
Page 11: Replacing The Functional Element
Replacing the Functional Element DANGER! Always disconnect, lock out, and tag the power before starting to service the pump. When servicing unit use non-sparking tools and use caution when removing or installing equipment to avoid generating a spark. 1. If a ball valve is installed down line from the pump, close it. 2. -
Page 12: Adjusting The Functional Element
(207 kPa) by turning down the pressure adjustment screw. This adjustment feature allows the use of the Red Jacket Standard pump with electronic line leak detection systems that require higher relief pressures and enhances performance of electronic line leak detection systems where field conditions have necessitated minor adjustments to the relief pressure. -
Page 13: Table 1.- Approximate Pressures At Shut-Off
4” Standard Pump Installation, Operation & Service Manual Adjusting the Functional Element NOTICE: If a siphon system is being utilized, it is especially important to follow the 5 psi (34 kPa) rule, that is the pump must create 5 psi more pressure than the relief pressure setting. For example, if a relief pressure of 25 psi (170 kPa) is desired, the pump in use must be capable of producing 30 psi (210 kPa). -
Page 14: Functional Element Parts List
4” Standard Pump Installation, Operation & Service Manual Adjusting the Functional Element Functional Element Parts List Table 2.- Adjustable Precision Functional Element AG (P/N 323-002-5) Item Part Number Description 108-574-4 Base Casting 017-526-1 Diaphragm 066-883-1 Poppet 072-641-1 O-Ring 41/64 x 5/64 076-421-3 Adjustment Screw 012-956-3... - Page 15 For technical support, sales or other assistance, please visit: www.veeder.com...
