Installation
3. The compression bushing is used to water seal the wiring entry port of the VSFC STP. Figure 17 through
Figure 19 illustrate the recommended installation of the bushing in the VSFC STPs with and without an I.S.
Barrier.
WARNING
YOU MUST FOLLOW THE WIRING INSTRUCTIONS IN THE VARIABLE SPEED FLOW
CONTROLLER INSTALLATION GUIDE- P/N 577013-815 WHEN CONNECTING POWER AND
PRESSURE TRANSDUCER/I.S. BARRIER WIRING TO THE RED JACKET VSFC STP.
Remove and discard plastic pins
from compression bushing (3)
vsfc\vsfcbushing1.eps
Figure 16. Compression Bushing
19
Tubing Kit Installation
