Introduction

Reference Manuals - As Required

• Variable Speed Flow Controller Installation Guide- P/N 577013-815
• PLLD (Pressurized Line Leak Detection) Site Prep and Installation Guide - P/N 576013-902
• FXV Leak Detectors Installation Instructions - P/N D042-106-1

Fuel Compatibilities

Pumps are designed to operate in a Class 1, Group D atmosphere and in accordance with CENELEC standard
and the European Directive 94/9/EC "Equipment for Potentially Explosive Atmoshpere" (II2 G Ex IIA T4).
All Models of the STP are UL Listed for the Following Fuel Compatibility
Diesel Gasoline
The STP is designed to be compatible with 100 percent gasoline, or diesel and 80 percent gasoline with 20
percent methanol, ethanol, TAME, ETBE, or MTBE (see Table 1 for UMP models and working parameters).
UMP200U20-2
The Red Jacket features an adjustable column pipe and electrical conduit that allows the overall length to be
adjusted to a wide range of overall pump lengths. By loosening a collet on the column pipe, the length of the UMP
may be varied by extending or retracting the column pipe. Three sizes of adjustable column pipe are available to
cover most pump length requirements (RJ1, RJ2, and RJ3).

Operation with Mechanical Leak Detection

A Red Jacket FXV Series leak detector can be installed in the pressure transducer port when mechanical leak
detection is desired.
NOTICE When a mechanical leak detector is installed in place of the pressure transducer, the STP
will automatically revert to fixed speed operation due to the absence of a pressure
transducer signal. Flow rates will be lower than what can be obtained with variable speed
operation.
To maintain variable speed operation with mechanical leak detection, a pressure transducer must be mounted in a
2-inch tee fitting that is installed in the discharge line within the submersible sump, and before the ball valve.
15%
Ethanol Methanol
Table 1. Maximum Specific Gravity And Maximum Viscosity
UMP Model
Gasoline and up to
15% 20%
MTBE
Maximum Specific
Gravity Maximum Viscosity
.95 70SSU at 60°F (15°C)
6
Reference Manuals - As Required
20% 20%
ETBE TAME
