Parts Lists

Conduit Bushing Kit Parts

Table 12 lists the Conduit Bushing 410486-001 and Figure 49 depicts the kit.
Item
(ref. Figure 49)
1

Die Spring Kit Parts

Table 13 lists the 410485-001 Die Spring Kit parts list.
Table 12. 410486-001 Conduit Bushing Kit Parts List
Part No.
410301-001
Bushing - Conduit
Figure 49. Conduit Bushing
Table 13. 410485-001 Die Spring Kit Parts List
Item
(ref. Figure 50)
Part No.
1
410133-001
Figure 50. Die Spring Kit
Description
1
Description
Die spring
1
2X
52
Conduit Bushing Kit Parts
Qty.
1
Qty.
2
