  • Page 1 Manual No: 577014-053 ● Revision: D Red Jacket UMP Replacement Instructions ® ® Red Jacket Quick-Set Submersible Pump...
  • Page 2 For the parts return procedure, please follow the instructions in the “General Returned Goods Policy” pages of the “Policies and Literature” section of the Veeder-Root North American Red Jacket Mechanical Products Price Book. Veeder-Root will not accept any return product without a Return Goods Authorization (RGA) number clearly printed on the outside of the package.
  • Page 3: Table Of Contents

    PRELIMINARY PRECAUTIONS ................2 REQUIREMENTS FOR USE..................3 OPERATING PRECAUTIONS .................3 Fuel Compatibilities ......................4 Electrical Data and Service Information Replacing the UMP for the Red Jacket STP ..............8 Replacing the UMP for the Standard STP ..............12 Test the Piping ........................15 Figures Figure 1.
  • Page 4: Safety Precautions

    Introduction Red Jacket 4-inch diameter non-CPT UMPs are interchangeable except that the lengths vary dependent upon the model and inlet area. When changing the model of the installed UMP, be sure to check the length (ref. Table 5/ Figure 1) so that proper clearance off the tank bottom is maintained (4 to 5” [100 to 125mm] for standard and TRAPPER™...
  • Page 5: Warnings And Instructions

    In addition to the specified torque values noted in this manual, when properly tightened, all flanged fittings should have metal-to-metal contact. The Red Jacket Submersible Turbine Pump’s A-weighted emission sound pressure level at work stations (inside the sump pit or on forecourt while refueling) does not exceed 70 dB.
  • Page 6: Requirements For Use

    • The Red Jacket is designed for use only at facilities dispensing motor fuels. • Application of The Red Jacket must be consistent with NFPA Code 30A, OSHA regulations, and federal, state and local fire codes, and other applicable local regulations.
  • Page 7: Fuel Compatibilities

    2014/34/EU “Equipment for Potentially Explosive Atmospheres” when installed with certified equipment. See Table 1 for UMP models and working parameters. All models of The Red Jacket STP or Standard STP are UL Listed for the following fuel compatibility Gasoline and up to...
  • Page 8: Electrical Data And Service Information

    Electrical Data and Service Information Table 2 and Table 3 show pump electrical service requirements for UMPs with end views A and B, respectively. Table 4 shows pump electrical service requirements for EN 15268 UMPs with end view B. Table 2. Electrical Service Information (For Umps Containing A Franklin Motor With End View A) - For STPs With UL, cUL, 03ATEX0237289X, 04ATEX0330285X, 06ATEX6050X, ANZEX 04.3005X Or POCC 05.B02160 Markings Required power supply rating for 60 Hz, 1 phase pumps is 208 - 230 Vac.
  • Page 9: Table 3. Electrical Service Information (For Umps Containing A Faradyne Motor With End View B) - For Stps With Ul, Cul, 03Atex0237289X, 04Atex0330285X Or 06Atex6050X Markings

    8.0 - 9.7 410164-003 (40) UMP200U3-4 When using a Red Jacket IQ Control Unit with an UMP containing a Faradyne motor, IQ software 805-001C (Version3.2) or newer, is required for proper operation of the system. The UMPs will have an ‘FM’ designation printed on the UMP shell.
  • Page 10: Table 5. Ump Model Dimensions

    The optional trapper intake screen is available as a field installed accessory. Trapper options will increase the length of the UMP by 3.3 inches (83 mm). For installation instructions, see Red Jacket installation instructions #051-256-1. For models with floating suction adapter, add 2-3/8 inches (59 mm) and 4 pounds (1.8 kg).
  • Page 11: Replacing The Ump For The Red Jacket Stp

    UMP Replacement Instructions Replacing the UMP for the Red Jacket STP Table 6. Approximate Pump Shut-Off Pressures UMP Model Approximate Shut-Off Pressure X4AGUMP150S3, X4UMP150U3 40 psi (275 kPa) .74 SG @ 60°F (15°C) X4AGUMP150S17, X4UMP150U17 39 psi (267 kPa) .74 SG @ 60°F (15°C) AGUMP200S1-3, UMP200U1-3 43 psi (297 kPa) .74 SG @ 60°F (15°C)
  • Page 12: Figure 2. Extractable Lock-Down Nuts

    UMP Replacement Instructions Replacing the UMP for the Red Jacket STP Protective plug - remove to access service screw Air purge screw Contractor's box Extractable Capacitor access lock-down cover nut (M12 flanged) Extractable lock-down 053-6 nut (M12 flanged) Figure 2. Extractable Lock-Down Nuts Confirm that the lifting eyebolt is properly torqued to 10 ft-lbs (13.6 N•m) with a...
  • Page 13: Figure 4. Verifying Pigtail's Female Connector Is Seated Properly In Discharge Head

    UMP Replacement Instructions Replacing the UMP for the Red Jacket STP 8. Pull the pigtail connector in the discharge head out far enough to see the o-ring in the sidewall of its socket (see Figure 4). Remove the connector’s o-ring from the connector’s socket and discard it. Get a 0.551” ID x 0.070’’...
  • Page 14: Figure 5. Locating Packer And Manifold O-Rings

    UMP Replacement Instructions Replacing the UMP for the Red Jacket STP Extractable wiring compartment cover o-ring (-928 [2.090'' ID x 0.118'' wide]) Upper extractable o-ring Leak detector port o-ring (-345 [3.975'' ID x 0.210'' wide]) (-228 [2.234'' ID x 0.139'' wide]) Contractors box o-rings (-928 [2.090'' ID x...
  • Page 15: Replacing The Ump For The Standard Stp

    UMP Replacement Instructions Replacing the UMP for the Standard STP 17. If applicable, open the ball valve down line from the pump. Replacing the UMP for the Standard STP WARNING Disconnect, lock out, and tag power at the panel before starting to service the pump.
  • Page 16: Figure 7. Ump Bolts And Gasket

    UMP Replacement Instructions Replacing the UMP for the Standard STP 7. Lift out the extractable unit allowing the pump to drain into the tank before complete extraction. CAUTION DO NOT damage the surface above the discharge port. The o-ring below the leak detector port seals on this surface.
  • Page 17: Figure 8. Verifying Pigtail's Female Connector Is Seated Properly In Discharge Head

    UMP Replacement Instructions Replacing the UMP for the Standard STP Pigtail female connector/indexing tab is out of its socket - this is the incorrect when attaching UMP! Pigtail female connector/indexing tab is fitted in notch of its socket - this is the correct position before attaching UMP! Insert the positioning dowel Connector's o-ring...
  • Page 18: Test The Piping

    UMP Replacement Instructions Test the Piping Test the Piping 1. Block lines at each dispenser by tripping dispenser shear valve. Remove line test plug on the packer for this test. 2. Close pump check valve by turning the vent closing screw on the Pressurstat/functional element as far down as possible.
