Performance verification
96
10. Set the test signal on the SPG8000 to 75% Color Bars (75% White) as follows:
a. Press the down (▼) arrow button until you see TEST SIGNAL in the
menu, and then press the ENTER button.
b. Press the right (►) arrow button until you see 75% Color Bars (75%
White).
c. Press the ENTER button.
11. Measure the jitter on the WFM8300 as follows:
a. Set the WFM8300 vertical gain to 5x.
b. Set the WFM8300 horizontal magnification to 10x.
c. Center an eye crossing on the WFM8300 screen.
d. Press the WFM8300 Display button, and then turn on Infinite Persistence
and set the waveform intensity to 50%.
e. Turn on the WFM8300 time cursors.
f. Shift the WFM8300 trace position to restart the persistence. Wait
30 seconds, and then use the time cursors to measure the width of the eye
at the narrowest point on the WFM8300 display.
12. Record the jitter reading in the test record.
13. Move the cable from the SDI 1A connector to the SDI 1B connector.
14. Repeat steps 4 through 12 for the SDI 1B output using the following format:
Option 3G installed: select 1080 59.94p
Option 3G not installed: select 1080 59.94i
15. Repeat steps 2 through 12 for the SDI 1B output, but change the Output Mode
to HD (1920 x 1080) and the format to 1080 24p.
16. Move the cable from the SDI 1B connector to the SDI 2A connector.
17. Press the SDI button on the SPG8000 until you see SDI 2: OUTPUT MODE.
18. Repeat steps 2 - 12 for the SDI 2A output.
19. Move the cable from the SDI 2A connector to the SDI 2B connector.
20. Repeat steps 14 - 15 for the SDI 2B output.
