4. SPECIFICATIONS

4.1.1 Matrix 6

ZONES
Number of programmable zones – 6
Zone loop types – Normally Open, Normally Closed,
SEOL, DEOL
Zone loop current – 0.5mA max.
Zone loop timers – 0.3sec. (normal zones),
30 ms (Fast Zones)
Zone wire resistance – not more than 470Ohm
PGM OUTPUTS
Number of programmable outputs – 4
Output types – up to 36
PGM1 – Relay Contacts, 30V DC @ 3A
PGM2 – Transistor Open Collector, 200mA
PGM3 – Transistor Open Collector, 200mA
PGM4 – Transistor Open Collector, 500mA
DIGITAL COMMUNICATOR
Digital communicator
–
Lightning protection – 6.75kV/125Amps
MECHANICAL
Dimension – 340 х 280 х 101mm
Material & colour – Metal / White Polymer
ENVIROMENTAL
Operation temperature: 0 to +40 º C
Storage temperature: –20 to +40 º C
When all parts are working normally, this equipment in combination with the PSTN and suitable ARC
RINS546-10
Analogue line
equipment will meet the requirements of ATS2.
This product is suitable for use in systems designed to comply with
PD6662:2010 at Security Grade 2 and Environmental Class 2.
Matrix 6/816 Installation Manual
POWER SUPPLY
Power input – 17V AC
Low voltage output 13.8V DC regulated
–
Max. capacity power output (incl. panel)
Max. power for ext. devices (excl. battery)
TRANSFORMER REQUIRED
For 230VAC, Primary – 230VAC, 50Hz, 20W min.
Secondary – 17VAC, 1.25A
For 120VAC, Primary – 120VAC, 50Hz, 50W min.
Secondary – 16.5VAC, 40VA
CURRENT CONSUMPTION
Matrix 6 PCB (alone) – 60mA
Remote keypad MX-ICON – 50mA
Remote keypad MX-LED – 60mA
BATTERY
Type – Lead Acid rechargeable
Battery Charge commencing – min. 5.5V
Battery Capacity – 2.8A/h ... 7.2A/h
Protection on BAT terminals – short & reverse
FUSE CONTROL
AC input – 2A (quick blow F1L)
Auxiliary supply output
RKP supply output 1A (quick blow F1L)
–
Battery Input – 5A (slow blow T5H)
1.25A
–
– 0.6A
1A (quick blow F1L)
–
