ZONES
Number of programmable zones – 8, expandable to 16
Zone loop types – Normally Closed, Normally Open,
SEOL, DEOL
Zone loop current – 0.5mA max.
Zone loop timers – 0.3sec (normal zones)
30 ms (Fast Zones)
Zone wire resistance – not more than 470Ohm
PGM OUTPUTS
Number of programmable outputs – 7
Output types – up to 36 for PGMs1-6, 37 for PGM7
PGM1 – Relay Contacts, 30V DC @ 3A
PGM2 – Transistor Open Collector, 200mA
PGM3 – Transistor Open Collector, 200mA
PGM4 – Transistor Open Collector, 500mA
PGM5 – Transistor Open Collector, 200mA
PGM6 – Transistor Open Collector, 200mA
Siren – Transistor Open Collector, 500mA
DIGITAL COMMUNICATOR
Digital communicator
–
Lightning protection – 6.75kV/125Amps
MECHANICAL
Dimension – 340 х 280 х 101mm
Material & colour – Metal / White Polymer
ENVIROMENTAL
Operation temperature: 0 to +40 º C
Storage temperature: –20 to +40 º C
NOTE: The battery charging voltage is microprocessor controlled and switched on or off as
needed. In order to measure this voltage the battery MUST be connected, otherwise a false
voltage will be measured.
When all parts are working normally, this equipment in combination with the PSTN and suitable ARC
Page 32
Analogue line
equipment will meet the requirements of ATS2.
This product is suitable for use in systems designed to comply with
PD6662:2010 at Security Grade 2 and Environmental Class 2
POWER SUPPLY
Power input – 17V AC
Low voltage output 13.8V DC regulated
–
Max. capacity power output (incl. panel)
Max. power for ext. devices (excl. battery)
TRANSFORMER REQUIRED
For 230VAC, Primary – 230VAC, 50Hz, 20W min.
Secondary – 17VAC, 1.25A
For 120VAC, Primary – 120VAC, 50Hz, 50W min.
Secondary – 16.5VAC, 40VA
CURRENT CONSUMPTION
Matrix 816 PCB (alone) – 60mA
Remote keypad MX-ICON – 50mA
On-board expander – 1mA
BATTERY
Type – Lead Acid rechargeable
Battery Charge commencing – min. 5.5V
Battery Capacity 2.8A/h ... 7.2A/h
–
Protection on BAT terminals – short & reverse
Low Battery Cut-Off – 10.4V
FUSE CONTROL
AC input – 2A (quick blow F1L)
Auxiliary supply output
RKP supply output 1A (quick blow F1L)
–
Battery Input – 5A (slow blow T5H)
1.25A
–
0.6A
–
1A (quick blow F1L)
–
RINS546-10
