Matrix 816
NOTE: PGM1 must be programmed as "External Bell". PGM 2 (in this example) must be
programmed as "Follow Strobe".
RINS546-10
BELLE
С1
external
с
ombined
Contacts position when output is off
sounder
(
relay coil is de-energized
Matrix 6/816 Installation Manual
PGM output stage diagram
Relay output
PGM 1
NO1 NC1
)
Transistor output
PGM 2, PGM 3 and PGM 4
PGM
10К
4К7
Page 23
