2.3 Power Supply & Telephone Line Wiring

2.3.1 Matrix 6

Transformer
230V/17V
~ 17V
To mains
~ 230V

2.3.2 Matrix 816

Transformer
230 /17 V V
~ 17V
To mains
~ 230 V
RINS546-10
Battery 12V
Battery 12V
Matrix 6/816 Installation Manual
To analogue
telephone
network
Telephone terminals
cross point
RING
TIP
telephone network
telephone equipment
To other
telephone
equipment
R-1
T-1
To analogue
To other
Telephone terminals
cross point
RING R-1
TIP T-1
Page 7
