3.2 Keypad Indications

Supply
Illuminated
Blinking
Extinguished
Illuminated
Ready
Blinking
Extinguished
Illuminated
Alarm
Slow Blinking
Fast Blinking
Extinguished
Illuminated
Tamper
Blinking
Extinguished
Illuminated
P.A.
Blinking
Extinguished
Fire Illuminated
Blinking
Extinguished
Illuminated
Fault
Blinking
Extinguished
Illuminated
Armed
Blinking
Extinguished
Disarmed Illuminated
Blinking
Extinguished
Page 30
Rest of the World
Correct AC & DC power sources
Indicates DC source (battery) fault
Indicates AC fault / no power to
panel
OK to Arm, no open zones
Programming function is active
One or more open zones
In Log: FTA - zone activation
Active alarm in FTA mode.
A latched alarm or fault needs clearing 'VIEW THE LOG'
No active alarms
Indicates a tamper condition (used in log display)
Indicates a tamper condition in FTA mode
No tamper alarm active
Indicates a PA alarm condition (used in log display)
Indicates a PA alarm condition in FTA mode
No PA active
Indicates a Fire alarm condition (used in log display)
Indicates a Fire alarm condition in FTA mode
No Fire alarm active
Indicates a system Fault
Keypad is in engineers mode
No Fault active
The panel is armed
Indicates the panel is arming with omitted zones
The panel is not armed
The panel is disarmed
Keypad is in user menu mode
The panel is not disarmed
Denmark, Norway, Finland &
Sweden
AC power is OK
Indicates an AC fault
No power to the panel
