Levelflex FMP56, FMP57 HART
Endress+Hauser
12.6

Configuration of the current outputs

12.6.1

Factory setting of the current outputs for level measurements

Current output Allocated measuring
vlaue
1 Level linearized
1)
2 Relative echo amplitude
1) for devices with 2 current outputs
12.6.2

Adjustment of the current outputs

The current outputs can be adjusted in the following submenus:
Basic settings
Setup → Advanced setup → Current output 1 to 2
Advanced settings
Expert → Output 1 to 2 → Current output 1 to 2
See "Description of Device Parameters" GP01000F
Commissioning via operating menu
4mA value
0% or the corresponding
linearized value
0 mV
20mA value
100% or the corresponding
linearized value
2 000 mV
91
