Endress+Hauser Levelflex FMP56 Operating Instructions Manual page 25

Levelflex FMP56, FMP57 HART
Endress+Hauser
60
50
40
30
20
10
0
0
 5 Silica sand in silo with smooth metallic walls; tensile load as a function of level L for rope diameters 6mm
(0,24 in) and 4mm (0,16 in)
A Silo diameter 12 m (40 ft)
B Silo diameter 9 m (30 ft)
C Silo diameter 6 m (20 ft)
D Silo diameter 3 m (10 ft)
18
16
14
12
10
8
6
4
2
0
0
 6 Polyethylene pellets in silo with smooth metallic walls; tensile load as a function of level L for rope
diameters 6mm (0,24 in) and 4mm (0,16 in)
A Silo diameter 12 m (40 ft)
B Silo diameter 9 m (30 ft)
C Silo diameter 6 m (20 ft)
D Silo diameter 3 m (10 ft)
5 10 15 20 25
L [m]
5 10 15 20 25
L [m]
Mounting
40
36
32
28
A
B
24
20
C
16
12
D
8
4
0
30 35
12
10
A
8
B
6
C
4
D
2
0
30 35
A0017170
A0017171
25
