Levelflex FMP56, FMP57 HART
Maximum value
Navigation
Prerequisite
Description
User entry
Factory setting
Diameter
Navigation
Prerequisite
Description
User entry
Factory setting
Additional information
Intermediate height
Navigation
Prerequisite
Description
User entry
Factory setting
Endress+Hauser
 Setup → Advanced setup → Linearization → Maximum value
Linearization type (→  156) has one of the following values:
• Linear
• Pyramid bottom
• Conical bottom
• Angled bottom
• Horizontal cylinder
• Sphere
Linearized value corresponding to a level of 100%.
–50 000.0 to 50 000.0 %
100.0 %
 Setup → Advanced setup → Linearization → Diameter
Linearization type (→  156) has one of the following values:
• Horizontal cylinder
• Sphere
Diameter of the cylindrical or spherical tank.
0 to 9 999.999 m
2 m
The unit is defined in the Distance unit parameter (→  138).
 Setup → Advanced setup → Linearization → Intermediate height
Linearization type (→  156) has one of the following values:
• Pyramid bottom
• Conical bottom
• Angled bottom
Height of the pyramid, conical or angled bottom.
0 to 200 m
0 m
Operating menu



159
