Embest SBC8600B User Manual page 9

Embest Technology Co., Ltd

Input Voltage: 3.3V
Processor

1GHz ARM Cortex™-A8 32-Bit RISC Microprocessor
NEON™ SIMD Coprocessor
32KB/32KB of L1 Instruction/Data Cache with Single-Error Detection
(parity)
256KB of L2 Cache with Error Correcting Code (ECC)

SGX530 Graphics Engine

Programmable Real-Time Unit Subsystem
Memories

512MB NAND Flash

2*256MB DDR3 SDRAM
Extension Interfaces and Signals Routed to Pins

Two 0.4-pitch 40-pin DIP Interfaces

A TFT LCD Interface (Support LCDs with 24-bpp parallel RGB
interface)

Two USB2.0 High-Speed OTG Interfaces

Six UART Interfaces

A SPI Interface

Two 10/100 /1000Mbps Ethernet MAC(EMAC) with Management Data
Input/Output(MDIO) Module

A Multichannel Audio Serial Ports (McASP)

8-Channel 12bit ADC Interface

Three IIC Signals

Two 4-line SD/MMC card interfaces

GPMC Signals
Note:
Some of the pins are multiplexed for UART、 IIC、 SPI、 CAN. Please refer to the CPU datasheet
