EB-SAM3U Development Board User Guide
Rev. 1.1
Release: 2011-07-26
Embest info & Tech Co., Ltd.
Address： 509 Room, Luohu Sci&Tech Edifice, No.85, Taining Road, Luohu
Zone, Shenzhen
Telephone: 86-755-25504951 25505451 25532557
Fax: 86-755-25616057
E-mail:
sales.cn@embedinfo.com
support.cn@embedinfo.com
Website:
http://www.embedinfo.com
http://www.embed.com.cn
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Embest EB-SAM3U
Summary of Contents for Embest EB-SAM3U
- Page 1 EB-SAM3U Development Board User Guide Rev. 1.1 Release: 2011-07-26 Embest info & Tech Co., Ltd. Address： 509 Room, Luohu Sci&Tech Edifice, No.85, Taining Road, Luohu Zone, Shenzhen Telephone: 86-755-25504951 25505451 25532557 Fax: 86-755-25616057 E-mail: sales.cn@embedinfo.com support.cn@embedinfo.com Website: http://www.embedinfo.com http://www.embed.com.cn...
- Page 2 AT91SAM3U4 Chips Based on Atmel ARM Cortex-M3 Kernel The EB-SAM3U board is a new evaluation board based on Atmel corp. AT91SAM3U series prosessors. The board features rich interfaces,which not only provides a good platform for application development,but also is the first choice for learners. Combining with our company's debugging tools ULINK2, it will offer your a better development environment for saving time and improving efficiency.
-
Page 3: Table Of Contents
目录 .................. 1 CHAPTER I JUMPERS ............... 2 CHAPTER II EVALUATION KIT HARDWARE 2.1 Board Overview .................... 2 2.2 EB‐SAM3U Block Diagram ................. 4 2.3 Processor ...................... 4 2.4 Memory ...................... 4 2.5 Clock Circuitry .................... 5 2.6 Reset and Wake‐Up Circuitry ................ 5 2.7 ... -
Page 4: Chapter I Jumpers
Chapter I Jumpers The EB-SAM3U board jumpers are used for many purposes such as internal Flash Memory reinitialization, power current measurement and other configurations. Table 1. Jumpers Setting Label Default Feature Setting ERASE Open Close it to reinitialize the Flash content and some of its NVM bits. -
Page 5: Chapter Ii Evaluation Kit Hardware
www.embedinfo.com/en Chapter Ⅱ Evaluation Kit Hardware 2.1 Board Overview Table 2. A List of Hardware Interfaces TFT LCD Connector UART DB9 male connector USART DB9 male connector HEADPHONE LINE-OUT Audio LINE-IN MONO/STEREO MICRO INPUT SD/MMC Socket USB Device(B-type) interface JTAG interface Power +5V Power supply by USB external pins(at the back of the board) - Page 6 www.embedinfo.com/en BNC interface1 supporting ADC12B BNC interface2 supporting ADC0 SAM3 chip PSRAM NAND Flash(under the LCD) Touch Screen controller(under the LCD) RS232 Transceiver 1 RS232 Transceiver 2 WM8731 CODEC(under the LCD) Temperature Sensor USB Slave Device interface MN10 Voltage Regulator MN11 LM4040-2.5 PNP NRST button...
-
Page 7: Eb-Sam3U Block Diagram
The AT91SAM3U features an External Bus Interface (EBI) that permits interfacing to a broad range of external memories and virtually to any parallel peripheral. The EB-SAM3U board is equipped with two kinds of memory devices connected to the SAM3U4E EBI: ·... -
Page 8: Clock Circuitry
· A 96 to 192 MHz programmable PLL (input from 8 to 16 MHz), capable of providing the clock MCK to the processor and to the peripherals. The EB-SAM3U board is equipped with one 12 MHz crystal, one 32,768 Hz crystal and an external clock input connector (optional, not populated by default). -
Page 9: Leds
The USART is also associated with PDC channels for TX/RX data access. There are 3 USARTs on the SAM3U4E device, EB-SAM3U connects the USART1 bus (including TXD, RXD, RTS, CTS handshake signals control) to the DB9 male connector J3 through the RS232 Transceiver MN6. -
Page 10: Jtag
12 JTAG A standard 20-pin JTAG connector is implemented on the EB-SAM3U for any ARM JTAG emulator connection, such as SAM-ICE. Note that the NRST net is connected to the system button BP1, and is also used to reset the LCD module. -
Page 11: Adc
If these two ports need to work separately, R82 and/or R84 should be removed. Figure 2. ADC Input 16 User Buttons 2 user buttons on the EB-SAM3U are connected to PIO lines, and are defined as left and right buttons by default. 17 Temperature Sensor A temperature sensor MCP9800 is connected to the AT91SAM3U TWI bus. -
Page 12: Sd Card
(freeing these dedicated PIO lines for other custom usage). 18 SD Card The EB-SAM3U has an MMC/MMCPlus high-speed 8-bit multimedia interface. This interface is used as a 4/8-bit interface, connected to an 8-bit SD/MMC card slot with card detection. -
Page 13: Chapter Iii Software Development And Examples
www.embedinfo.com/en NandFlash Read and write to external NANDFLASH according SMC. SRAM Test the external SRAM. Read and write it. If success,D2 lights,else D3 lights. This procedure mainly tests TC module of the board. Configure TC working in Waveform Mode. RA=0x1000. It will generate interrupt and turn on LED light when generating Comparing matchs. - Page 14 www.embedinfo.com/en or click the shortcut icon: to download the image. click 5. After download, execute Debug/Start/Stop Debug Session(Ctrl+F5) to debug as follows： or click shortcut con： to start debug.After click, assembly code will show in the main workspace, if you want to see source code, you can right click mouse before Step, choose “Show Source Code for current Address”...
- Page 15 www.embedinfo.com/en source code will appear in the workspace。 6. You can make use of the debug shortcut icon in the window to execute debug process, the icon as follows： 12/16...
-
Page 16: Appendix A: After-Sale Service
Appendix A: After-sale Service Embest is at your service, and we have special Technical Support Engineers to provide support and consultation in forms of telephone,E-mail,Fax and so on. • TEL:0755-2550 9834 • FAX:0755-2561 6057 • Special E-mail of Technical Support Engineers: o Technical Support for ARM development tools:support@embedinfo.com...
