Technical data

Tetrix 152, 352, 552 RC Plasma CW GR

8 Technical data
Performance specifications and guarantee only in connection with original spare and
replacement parts!
8.1 Tetrix 152, 352, 552 RC Plasma CW GR
Welding current
Welding voltage
Plasma current (Hilibo)
Duty cycle at 40 °C ambient temperature
100% DC
60% DC
Load alternation
Floating voltage
Mains voltage (tolerances)
Frequency
Mains fuse (safety fuse, slow-blow)
Mains connection lead
Max. connected load
Recommended generator rating
Cosϕ
Insulation class/protection classification
Ambient temperature*
Machine cooling/torch cooling
Workpiece lead
Dimensions L x W x H in mm
Weight
EMC class
Constructed to standards
Ambient temperature depends on coolant!
*
Observe the coolant temperature range for the welding torch cooling!
58
NOTE
152
5 A to 150 A 5 A to 350
25.2 V bis 31.0 V 25.2 V to 39.0 V
5 A to 80 A•
(factory setting 10 A, can be adjusted using PCT 300
software)
150 A
-
∧
10 min. (60% DC 6 min. welding, 4 min. pause)
3 x 400 V (-25% to +20%)
50/60 Hz
3 x 16 A
H07RN-F5G6 H07RN-F5G6
7.2 kVA 18.6 kVA
9.7 kVA 25.1 kVA
-20 °C to +40 °C*
Fan/gas or water
2
70 mm
1125
460
IEC 60974-1, -3, -10;
NOTE
352 552
5 A to 550 A
25.2 V to 47.0 V
350 A 420 A
- 550 A
79 V
3 x 35 A 3 x 35 A
H07RN-F5G6
34 kVA
45.9 kVA
0.99
F/IP 23
2
95 mm 95 mm
930
132 kg
A
;
099-008724-EW501
2
08.01.2012
