"Insufficient wire" sensor

4.4 "Insufficient wire" sensor
Item Symbol Description
1
2
3
4
24
0
"Insufficient wire" sensor control lead plug
Wire feed rapid-action closure
Connection to wire source
Wire exit rapid-action closure
Connection to wire feed connection hose
"Insufficient wire" sensor
A warning is issued as soon as the end of the wire (insufficient wire) is reached.
The process will not be shut down.
