Machine description – quick overview
Tetrix 152, 352, 552 RC Plasma CW GR
Item Symbol Description
1
digital
2
3
analog
4
5
6
7
8
9
10
11 X13
12
13
14
15
16
17
18
19
20
21
18
0
Interfaces connection socket (15-pole)
Mains connection cable
19-pole mechanised welding interface (analogue)
(See chapter entitled "Design and function > interfaces".)
Key button, automatic cutout
Wire feed motor supply voltage fuse
press to reset a triggered fuse
7-pole connection socket (digital)
For connecting digital accessory components
23-pole connection socket (analogue)
Mechanised welding torch connection
Connection socket, welding current -
Welding torch connection
Connection socket, "+" welding current
Connection for workpiece lead
7-pole connection socket (digital)
Wire feed unit connection
12-pole connection socket (analogue)
Wire feed unit connection
"Insufficient wire" sensor connection
Pilot current connection socket
Plasma welding torch nozzle potential
Cooling unit voltage supply
Protective contact socket
G1/4" connecting nipple, shielding gas, outlet
Connection to welding torch
Connecting nipple G1/4" shielding gas, inlet
Connection to pressure regulator
G1/4" connecting nipple, plasma gas, outlet
Connection to welding torch
Connecting nipple G1/4" plasma gas, inlet
Connection to pressure regulator
Quick connect coupling (red)
Coolant return to cooling unit
Rapid-action closure nipple
Coolant return from welding torch
Cooling air outlet
Intermediate hose package strain relief
