Settings
8.2 (6.3) Interface
Set the parameters for connection of other devices to the ISOMETER® in the interface
menu:
8.2 (6.3.1) Mode
Settings for data transfer with other devices via the BS-Bus.
8.2 (6.3.2) BMS
8.2 (6.3.2.1) BMS address
Select an address between 1 and 90 for the BMS bus.
8.2 (6.3.3) Modbus/RTU
8.2 (6.3.3.1) Address
select an Adress between 1 and 247
8.2 (6.3.3.2) Baud rate
•9,6 kB
•19,2 kB
•37,4 kB
•57,6 kB
•115 kB
8.2 (6.3.3.3) Parity
•even
•odd
•none
8.2 (6.3.3.4) Stop Bits
•1
•2
•auto
40
Settings
8.2 (6.4) Display
Adjust the display brightness for the ISOMETER® in the display menu:
8.2 (6.4.1) Brightness
Adjust the display brightness between 0 % and 100 % in steps of 10.
If no button is pressed on the display for 15 minutes, the brightness of the display will be
reduced. If now a button is pressed, the normal brightness is restored.
8.2 (6.5) Password
Use the password function to protect the device parameters against unauthorised adjust-
ment. The default password is 0000.
8.2 (6.5.1) Password
Enter an individual four-digit password.
8.2 (6.5.2) Status
Decide whether the password query should be used:
•on Password query active
•off Password query inactive
8.2 (6.6) Commissioning
In the commissioning menu, you can open the ISOMETER®'s commissioning wizard again.
8.2 (6.7) Service
The service menu can only be accessed by Bender service staff.
8.2 7.0 Info
The ISOMETER®'s current settings can be viewed in the Info menu. Navigate through the
different views using the and buttons:
Device name, serial number, article number
•Info - Device
Software version measurement technique,
•Info - Software
software version HMI
•Info - Measurement
Set profile, locating current and EDS mode
technique
•Info - Clock Time, date, summer time
•Info - BMS Address of the RS-485 interface
