Settings
Do not carry out a manual test during a manually started insulation fault
location, since the insulation fault location would be aborted by that.
8.2 (2.1.2) Current
Risk of malfunctions due to excessive locating current on sensitive
system parts!
The locating current flowing between the IT system and earth can cause
controller faults in sensitive parts of the system, such as the PLC or relay.
Ensure that the level of the locating current is compatible with the system
to be monitored.
Set the maximum locating current on the ISOMETER®. You can find the device-specific
maximum locating currents in the table below.
for EDS441-x
•1 mA
•2.5 mA for EDS441-x
•5 mA for EDS441-x
for EDS440-x
•10 mA
•25 mA for EDS440-x
•50 mA for EDS440-x
8.2 (2.2) Scanning channels
For a successful insulation fault location, all active measuring channels must be deter-
mined. Indicate if you would like to start the search for EDS measuring channels.
Aborts the scan process.
•Cancel
•Start Starts the scan process (search) for EDS channels.
Also refer to see "Commissioning flow chart insulation fault monitoring" on page
If one bus device fails, the ISOMETER® asks whether it should search for
measuring channels and then automatically determines all channels
again. Also refer to "Alarm messages" ab Seite
33
Settings
8.2
During initial commissioning all channels are inactive. Before configuring the channels
they must be activated in this menu.
Select which measuring channels you would like to activate. Multiple selection is possible
here.
•Select all
•No selection
•Invert selection
•Channel 1(BS 2/1)
...
•Channel 12 (BS 2/12)
Navigate to the required selection point using the
lection by pressing "OK". The selected channels are activated with the
8.2
Use group settings to adjust the settings for several EDS or EDS channels simultaneously
or to read out settings.
If you would like to make settings for each EDS or each EDS channel individually, then
please refer to the menus from
22.
48.
(2.3) Activating channels
All measuring channels are selected.
No channel is selected.
The current selection is inverted.
A single channel is selected.
(2.4) Group settings
"8.2 (2.5) Channel"
The values indicated in the group settings are not the values of the individ-
ual EDS but the factory settings or the last adjusted values in the
ISOMETER®. To see the values of the individual EDS, please navigate to the
menu points "8.2 (2.5) Channel"
and buttons. Confirm your se-
button.
to "8.2 (2.8) Device".
to "8.2 (2.8) Device".
