Settings
8.2
(2.4.4.3) Trigger
The locating current pulse of the ISOMETER® is synchronised with the measurement
technology in the EDS via the BB bus or the BS bus. This allows a more reliable detection
of the locating current pulse in the event of disturbances.
Disturbances can be caused e.g. by variable-speed drives, rectifiers, actuators, noise fil-
ters, PLCs, or control electronics.
Synchronisation via BS bus or BB bus. The EDS only searches for insulation
•Com
faults if the insulation fault location has been started. Less time is needed
for the insulation fault location as with the setting "auto".
No synchronisation (e.g. if there is no BS bus or BB bus).
•auto
The EDS continuously searches for insulation faults.
If the trigger mode is set to "auto", the use of a portable EDS must be acti-
vated in the menu ( = "ON"), since the measurement method is corre-
spondingly adjusted at this menu point.
8.2
(2.4.4.4) Fault memory
Faults that only occur temporarily can be saved.
After eliminating the cause of fault, alarm messages remain stored
•on
until a RESET is carried out. This function applies to alarm and device
fault messages.
The EDS exits the alarm mode as soon as the cause of fault is
•off
eliminated.
8.2
(2.5) Channel
In this menu, each channel can be configured. Also refer to
8.2
(2.5.1) Name
Enter a name for the selected channel. This name will also be displayed on the gateways
and in the web server and can be edited via these as well.
8.2
(2.5.2) Current transformer monitoring
Refer to
"8.2 (2.4.1.2) CT
monitoring".
8.2
(2.5.3) Response value I
ΔL
Refer to
"8.2 (2.4.1.3) IΔL Response
value".
8.2
(2.5.4) Response value I
Δn
Refer to
"8.2 (2.4.1.4) IΔn Response
value".
37
Settings
8.2
In this menu, each output can be configured. Also refer to
8.2
Select the relay that you would like to configure.
•Relay 1 (BS 2/1)
...
8.2
Refer to
8.2
Refer to
8.2
Refer to
8.2
Refer to
8.2
Refer to
8.2
In this menu, each buzzer can be configured. Also refer to
8.2
Refer to
"8.2 (2.4.1)
Channel".
8.2
Refer to
8.2
Refer to
8.2
Refer to
(2.6) Outputs
(2.6.1) Relays
(2.6.1.1) TEST
"8.2 2.4.2.1.1
TEST".
(2.6.1.2) Operating mode
"8.2 2.4.2.1.2 Operating
mode".
(2.6.1.3) Function 1
"8.2 2.4.2.1.3 Function
1".
(2.6.1.4) Function 2
"8.2 2.4.2.1.3 Function
1".
(2.6.1.5) Function 3
"8.2 2.4.2.1.3 Function
1".
(2.6.2) Buzzer
(2.6.2.1) TEST
"8.2 2.4.2.1.1 TEST".
(2.6.2.2) Function 1
"8.2 2.4.2.1.3 Function
1".
(2.6.2.3) Function 2
"8.2 2.4.2.1.3 Function
1".
(2.6.2.4) Function 3
"8.2 2.4.2.1.3 Function
1".
"8.2 (2.4.2)
Outputs".
"8.2 (2.4.2.2) Buzzer".
isoxx1685Dx-x25_D00272_05_M_XXEN/04.2018
