Settings
8.2 (2.4.2.4) Function 1
Refer to "8.2 2.4.2.1.3 Function 1".
8.2 (2.4.2.5) Function 2
Refer to "8.2 2.4.2.1.3 Function 1".
8.2 (2.4.2.6) Function 3
Refer to "8.2 2.4.2.1.3 Function 1".
8.2 (2.4.3) Dig. input
Select the digital inputs of the EDS that you would like to configure:
•Select all
•No selection
•Invert selection
•Dig. input 1 (BS 2/1)
•Dig. input 2 (BS 2/2)
Now make the settings for the digital inputs of the EDS selected before.
8.2 (2.4.3.1) Mode
The operating mode for the digital input can be set to the following values. For a descrip-
tion of the operating modes, refer to
:
lected
An event is carried out on the rising edge of the digital input (low to
•Active high
high).
An event is carried out on the falling edge of the digital input (high
•Active low
to low).
8.2 (2.4.3.2) t(on)
The response time t(on) after a switch-on signal can be set between 100 milliseconds and
300 seconds. For a description of the operating modes, refer to
8.2 (2.4.3.3) t(off)
The response time t(off) after a switch-off signal can be set between 100 milliseconds and
300 seconds. For a description of the operating modes, refer to
36
All digital inputs are selected.
No digital input is selected.
The current selection is inverted.
A single digital input is selected.
see "Mode" on page 40. The following can be se-
see "Mode" on page
"Mode" on page
Settings
8.2 (2.4.3.4) Function
•off
•TEST
•RESET
8.2 (2.4.4) Device settings
•Select all
•No selection
•Invert selection
•BS bus 2 (1-12)
8.2 (2.4.4.1) System type
Settings made to this menu point will only have an effect on connected
EDS460 and NOT on EDS44x devices.
Adjust the EDS to the IT system to be monitored.
•DC
•AC
•3AC
8.2 (2.4.4.2) Frequency
Settings made to this menu point will only have an effect on connected
EDS460 and NOT on EDS44x devices.
Configure the mains frequency of the IT system to be monitored.
40.
•50 Hz
•60 Hz
•400 Hz
40.
•DC
Digital input without function.
Device self test.
Reset of fault and alarm messages.
All devices are selected.
No device is selected.
The current selection is inverted.
DC system
Single-phase AC system
3AC system
