Settings
8.2 (2.4.1) Channel
Before configuring a measuring channel, you must activate it.
Select which measuring channel you would like to activate and configure.
•Select all All measuring channels are selected.
•No selection No channel is selected.
•Invert selection The current selection is inverted.
A single channel is selected.
•Channel 1 (BS 2/1)
•Channel 2 (BS 2/2)
•Channel 3 (BS 2/3)
Navigate to the required selection point using the
lection by pressing "OK". Activate the selected measuring channel using the
and navigate to its setting options.
8.2 (2.4.1.1) Current transformer (CT)
Set the used current transformer.
W.../WR.../WS.../
•Type A
W/WS8000
W...AB
•Type AB
8.2 (2.4.1.2) CT monitoring
Activate or deactivate the CT monitoring.
If CT monitoring is active, an alarm is signalled as soon as a fault occurs on a current trans-
former of an activated channel (short circuit or interruption).
CT monitoring is activated
•on
(the current transformers are monitored).
CT monitoring is deactivated
•off
(the current transformers are not monitored).
8.2 (2.4.1.3) I Response value
ΔL
Set the response value for I (main alarm for insulation fault location) between 200 μA
ΔL
and 10 mA. The response value must be below the set locating current
The permissible response value and the response sensitivity depend on
the connected EDS (EDS440x or EDS441x).
CAUTION
34
and buttons. Confirm your se-
button
.
Settings
8.2 (2.4.1.4) I Response value
Δn
Set the response value for I (alarm for residual current measurement) between 100 mA
Δn
and 10 A.
The permissible response value and the response sensitivity depend on
the connected EDS (EDS440x or EDS441x).
CAUTION
8.2 (2.4.2) Outputs
In this menu, the settings for the outputs of the EDS can be made.
•Relays
•Buzzer
•Dig. output
8.2 (2.4.2.1) Relays
Select the relays that you would like to configure.
•Select all All relays are selected.
No relay is selected.
•No selection
The current selection is inverted.
•Invert selection
•Relay 1 (BS 2/1) A single relay is selected.
•Relay 2 (BS 2/2)
8.2 2.4.2.1.1 TEST
The functional test of the relay can be activated or deactivated. This only applies to the
manual test and not to the cyclic device self test.
The manual test checks the switching function of the relay.
•on
•off The manual test does not check the switching function of the relay.
8.2 2.4.2.1.2 Operating mode
The relay operating mode can be adapted to the application.
Normally closed- N/C operation contacts11-12-14 / 21-22-24 (in
•N/C
fault-free condition, the alarm relay is energised).
Normally opened - N/O operation contacts 11-12-14 / 21-22-24 (in
•N/O
fault-free condition, the alarm relay is de-energised).
