Start-Up; Safety Instructions; 10.2 Automatic Adjustment X.tune - Burkert Positioner TopControl Basic 8696 Quick Start Manual

Operating voltage
Wire
Pin Configuration External circuit
color
4)
3 green GND
4 yellow + 24 V
Tab. 4: Pin assignment - operating voltage
Output signals to the control center (e.g. PLC) - (required for
analogue output option only)
Wire
Pin Configuration External circuit / signal level
color
4)
red Analogue
8
position
feedback +
7 blue Analogue
position
feedback GND
Tab. 5: Pin assignment - output signals of the control center - option
When the supply voltage is applied, the positioner is operating.
→ Actuate the automatic adjustment of the positioner, as
described in the chapter entitled "10.2 Automatic adjustment
4) The indicated colors refer to the connecting cable available as an
accessory (919061).
16
24 V DC ± 10 %
3
max. residual
4
ripple 10 %
8 + (0/4 – 24 mA)
GND
7
X.TUNE".
english
Type 8696

Start-up

10 START-UP
10.1

Safety instructions

WARNING!
Risk of injury from improper operation.
Improper operation may result in injuries as well as damage to
the device and the area around it.
▶ Before start-up, ensure that the operating personnel are
familiar with and completely understand the contents of the
operating instructions.
▶ Observe the safety instructions and intended use.
▶ Only adequately trained personnel may operate the equip-
ment/the device.

10.2 Automatic adjustment X.TUNE

To adjust the positioner to local conditions, the X.TUNE
function must be run following installation.
WARNING!
Danger due to the valve position changing when the X.TUNE
function is running.
When the X.TUNE is running under operating pressure, there is
an acute risk of injury.
▶ Never run X.TUNE while a process is running.
▶ Take appropriate measures to prevent the equipment from
being accidentally actuated.
