→ Close the device (assembly tool: 674078
7) The assembly tool (674078) is available from your Bürkert sales office.

10.3 Control and display elements

A detailed description of the operation and functions of
the positioner and the communication software can be
found in the respective operating instructions.
NOTE!
Breakage of the pneumatic connection pieces due to rota-
tional impact.
▶ When unscrewing and screwing in the transparent cap, do
not hold the actuator of the process valve but the connection
housing.
Fig. 12: Open positioner
18
).
7)
Transparent cap
Body casing
Connection housing
Actuator
english
Type 8696
Start-up
→ Screw off the transparent cap of the positioner to operate the
keys and DIP switches.
LED 2
LED 1
Communica-
tions interface
Fig. 13: Description of the control elements
NOTE!
Breakage of the pneumatic connection pieces due to rota-
tional impact.
▶ When unscrewing and screwing in the transparent cap, do
not hold the actuator of the process valve but the connection
housing.
Damage or malfunction due to penetration of dirt and
humidity.
▶ To observe degree of protection IP65 / IP67, screw the trans-
parent cap in all the way.
→ Close the device (assembly tool: 674078
8) The assembly tool (674078) is available from your Bürkert sales office.
Key 1
DIP switches
Key 2
).
8)
