General information

4 GENERAL INFORMATION
4.1

Contact address

Germany
Bürkert Fluid Control System
Sales Center
Chr.-Bürkert-Str. 13-17
D-74653 Ingelfingen
Tel. + 49 (0) 7940 - 10 91 111
Fax + 49 (0) 7940 - 10 91 448
E-mail: info@burkert.com
International
Contact addresses can be found on the final pages of the printed
operating instructions.
And also on the Internet at:
www.burkert.com
4.2

Warranty

The warranty is only valid if the positioner Type 8696 is used as
intended in accordance with the specified application conditions.
4.3

Information on the internet

The operating instructions and data sheets for Type 8696 can be
found on the Internet at:
www.burkert.com
Type 8696
5

SYSTEM DESCRIPTION

5.1

Structure and function

Fig. 1: Structure 1
Positioner Type 8696 is an electropneumatic position controller for
pneumatically actuated control valves with single-acting actuators.
Together with the pneumatic actuator, the positioner forms a func-
tional unit.
The control valve systems can be used for a wide range of control
tasks in fluid technology and, depending on the application condi-
tions, different process valves from the Bürkert range can be com-
bined with the positioner. Angle seat valves, straight seat valves or
diaphragm valves of the Type 2300, 2301 or 2103 with an actuator
size of 50 mm are suitable.
english
Positioner
Actuator
Process valve
Valve body
7
