Technical data
6.7

Pneumatic data

Control medium: neutral gases, air
Quality classes in accordance with ISO 8573-1
Dust content Class 7:
Water content Class 3:
Oil content Class X: max. 25 mg/m³
Temperature range
control medium:
Pressure range
control medium:
Air output of pilot valve:
Connections:
2 3xx / 2103 (Element):
Model third-party device: S ocket connection G 1/8
Type 8696
max. particle size 40 µm,
max. particle density 10 mg/m³
max. pressure dew point
- 20 °C or min. 10 °C below the
lowest operating temperature
-10 – +50 °C
3 – 7 bar
7 l / min (for aeration and deaer-
N
ation)
(Q - value according to definition
Nn
for pressure drop from 7 to 6 bar
absolute)
P lug-in hose connector ∅ 6mm / 1/4"
Socket connection G 1/8
with M5 connection for connecting
to the third-party device
6.8

Electrical data

WARNING!
Only circuits with limited power may be used for UL approved
components according to "NEC Class 2".
Connections
Pilot valve
S upply voltage
Power input
Input resistance
for set-point value signal
Protection class
Analogue position feedback
max. load for current output
0/4 – 20 mA
Binary input
Communications
interface
english
C ircular plug-in connector
(M12 x 1, 8-pole)
24 V DC ± 10%
- max. residual ripple 10 %
≤ 3.5 W
1 80 Ω at 0/4 – 20 mA /
12 bit resolution
3 as per DIN EN 61140 (VDE 0140-1)
560 Ω
0 – 5 V = log "0",
12 – 30 V = log "1"
inverted input in reverse order
D irect connection to PC via USB
adapter with integrated interface
driver, communication with commu-
nications software.
