6.9

Factory settings of the positioner

Functions can be activated via DIP switches:
Function Parameter
CUTOFF Sealing function below
Sealing function above
CHARACT Select characteristic
DIR.CMD Effective direction set-point
value
Tab. 2: Factory settings - functions
Additional functions are described in the operating
instructions Type 8696.
These instructions can be found on the Internet at
www.burkert.com.
3) without change to the settings via the communications software a
linear characteristic is stored in FREE.
12
Value
2 %
98 %
FREE
3)
rise
english
Type 8696

Installation

7 INSTALLATION
Only for positioner without pre-assembled process valve.
7.1

Safety instructions

DANGER!
Risk of injury from high pressure in the equipment/device.
▶ Before working on equipment or device, switch off the pressure
and deaerate/drain lines.
Risk of electric shock.
▶ Before working on equipment or device, switch off the power
supply and secure to prevent reactivation.
▶ Observe applicable accident prevention and safety regulations
for electrical equipment.
WARNING!
Risk of injury from improper installation.
▶ Installation may be carried out by authorized technicians
only and with the appropriate tools.
Risk of injury from unintentional activation of the system and
an uncontrolled restart.
▶ Secure system from unintentional activation.
▶ Following assembly, ensure a controlled restart.
