Technical Highlights - Logic IO RTCU NX-200 Technical Manual

RTCU NX-200 Technical Manual V1.00
Advanced Automotive M2MI/IoT Gateway

Technical Highlights

Platform:
➢ Based on the RTCU M2M Platform.
➢ NX32L (NX32 for Linux) execution architecture.
▪
RTCU IDE development tool.
▪
Operates under a full and highly optimized Linux variant.
▪
Open and extendable with Platform SDK.
Hardware Core:
➢ Cortex-A5 32-bit ARM processor operating at 500 Mhz.
➢ Hardware floating-point and DSP instructions.
➢ 128 MByte LP-DDR RAM.
➢ 512 MByte NAND Flash (file-system).
➢ 16 MByte NOR flash (system boot).
➢ 8 MB Dataflash (persistent memory/datalogger).
➢ 128 KB SRAM with battery back-up (unlimited endurance).
➢ Real-time clock with battery back-up.
Security:
➢
Embedded firewall.
➢
TLS/SSL support with full certificate management.
➢
TLS/SSL support for all major TCP protocols, such as SMTP, MQTT, and sockets.
➢ Hardware assisted encryption/authentication: AES-128, AES-192, AES-256, DES, TripleDES, HASH,
RND and RSA signature.
Wireless Communication:
➢ Worldwide LTE Cat. 4 Multi-Band Cellular Engine.
➢ Dual SIM-card readers and support for eSIM.
➢ Wireless LAN (Wi-Fi).
➢ Classic and Low-Energy Bluetooth.
➢ Multi-constellation GNSS with GPS, GLONASS, and GALILEO.
➢ Optional: GNSS with Dead Reckoning.
Wired Communication:
➢ 100 Mbps Ethernet LAN interface.
➢ 2 x full CAN 2.0B controller with hardware filtering and multi-speed support.
➢ 1-Wire bus for accessories such as ID-button reader, temperature sensors, etc.
➢ 2 x USB host port for expandability.
➢ 2 x RS232 channels and 1 x RS485 channels.
I/O Interfaces:
➢ 5 x digital inputs and 4 x high-power solid-state digital outputs.
➢ 4 x flex inputs with dual-mode analog /digital operation.
➢ 2 x analog inputs with 12 bits resolution.
➢ Expandable I/O with standard Modbus modules.
