RTCU NX-200 Technical Manual V1.00
Advanced Automotive M2MI/IoT Gateway
I/O Interface
•
4 x digital solid-state digital output.
Max. 36 volt / 1.5 A per. channel.
Short-circuit, ESD, Inductive kick-back
protected up to 20 mH.
•
5 x digital inputs with ignition.
Logic high: 8 to 40 VDC.
Logic low: -5 to 3 VDC.
Impedance: 14 kohm @ 12V.
•
4 x flex-inputs. Dual mode operation:
Analog mode: 0..30VDC
Digital mode: 0..30VDC.
Impedance: 120 kohm @ 12V.
Multi configuration support.
•
2 x analog inputs.
Range is 0..10VDC.
Resolution: 12 bit
Accuracy: Typ. ±0.3% FSR @ 25°C.
Impedance: 40 kohm (V).
•
Protected against transients and low-
pass filtered.
Sensors
•
Temperature sensor.
•
3-axis Accelerometer. ±16g@16b.
•
3-axis Gyroscope. ±2000dps @16b.
•
3-axis Magnetometer. ±50 gauss @16b.
Electrical
•
Operating voltage: 8 to 36 VDC.
•
Short and reverse power protected.
•
5 VDC-out @ 300 mA.
•
Dual USB 5 VDC @ 500 mA.
Battery and Charger
•
On-board 2.6Ah (nominal) Li-Ion
battery.
•
Intelligent charger with temperature
throttle and sub-zero degrees support.
Logic IO ApS.
Holmboes Allé 14
8700 Horsens

Denmark

Power Management
•
Low-power modes.
•
Wait for Event: Timer, Digital input,
accelerometer, RS232, RS485, CAN,
Cellular, Power change state.
•
Wait for event, from: 0.4 mA@12V.
•
Supervision of supply voltage / type.
External Interfaces
•
Plug-compatible with the MX2 turbo.
•
SIM-card slots for mini-SIM card.
•
SD-CARD slot.
•
2 x mini-jack for audio in/out.
•
4 x LED indicators and 2 x DIP switches.
•
Reset/recovery switch.
•
RJ45 for RS232 with full control signals.
•
SMA Female connector for cellular.
•
SMA-RP connector for WLAN and BT.
•
SMA Female connector for GNSS.
•
USB 2.0 Host port connectors.
•
USB 2.0 Slave mini-USB connector.
•
TE-Connectivity "Mate'n'Lok':
RS232, RS485, CAN I/O, Power,
Communicaton.
Expandable
•
I/O expansion Modbus modules.
•
RFID-Reader*.
•
Additional Ethernet port.
•
Additional RS232 / RS485 ports.
•
Industrial USB hub.
•
Camera with HD video streaming.
•
Speaker and microphone.
Page 44 of 45
Physical Characteristics
•
Encapsulation: Aluminium profile.
•
Colour: Anodized natural grey.
•
Material: Aluminum and plastic.
•
Approx. 500 gram without accessories.
•
W 148 x H 34 x D 122 mm.
(without connectors / mounting flange).
Environmental Specification
•
Operating temperature: -40 to 65°C.
•
Battery charge temperature:
-10 to 45 °C.
•
Recommended storage temperature:
0 to 45°C.
•
Humidity: 5..90% (non condensing).
•
Ingress Protection: IP20 .
Approvals
•
2007/46/EC UN ECE R10 Rev. 05 (E1).
•
2014/53/EU Radio Equipment Directive.
•
2011/65/EU RoHS Directive.
•
Cellular:
GCF/CE/FCC/PTCRB/IC/Anatel/SRRC/NAL/
CCC/KC/NCC/JATE/TELEC/RCM/IFETEL/
FAC/NBTC/ICASA.
Warranty
•
Two-years return to factory parts and
labor.
•
Optional warranty up to 5 years.
(restrictions apply).
Technical data are subject to changes.
