RTCU NX-200 Technical Manual V1.00
Advanced Automotive M2MI/IoT Gateway
Accessories for cable assembly.
Order-code
RT-O-TYCO-H4
TYCO p/n: 794617-4
RT-O-TYCO-H6
TYCO p/n: 794617-6
RT-O-TYCO-H12
TYCO p/n: 1-794617-2
RT-O-TYCO-H16
TYCO p/n: 1-794617-6
RT-O-TYCO-CR
TYCO p/n: 794606-1
RT-O-TYCO-TOOL
TYCO p/n: 91501-1
Recommended tool:
Alternative tools:
Extraction tool:
Connector Mini USB-B
The USB port is for programming and communication with the RTCU IDE (RACP compliant
application). A standard USB cable with a connector length of 10mm on the USB-B end can be used
between the device and the PC
Connector Ethernet
This is a standard 10Base-T/100Base-TX IEEE 802.3 compliant Ethernet connector. Please use an
appropriate connector and cable, such as a standard CAT-5 twisted pair patch cable
Connector USB-Host
These are standard full-speed USB-A host port connectors and used for communication with
accessories connected to the host port. These ports are supplied internally, and current
consumption is limited to 500mA
Logic IO ApS.
Holmboes Allé 14
8700 Horsens
Denmark
Name
Tyco, Connector house 4 pins. Bag with 10 pcs
Tyco, Connector house 6 pins. Bag with 10 pcs
Tyco, Connector house 12 pins. Bag with 10 pcs
Tyco, Connector house 16 pins. Bag with 10 pcs
Tyco, Crimp Contacts for connector house. Wire size 0.2 to 0.5 mm
Bag with 100 pcs.
Tyco, Crimp hand tool for easy assembly of TYCO crimp contacts.
Wire size 0.2 to 0.5 mm
Tyco 91501-1 (0.20 to 0.50mm
Tyco 91502-1 (0.05 to 0.15mm
Tyco 843996-6 extraction tool. RS 495-9704, Farnell 1111477
Page 14 of 45
2
2 ) RS 495-9675, Farnell 1111475
) RS 495-9675, Farnell 1111476
2
.
2
