RTCU NX-200 Technical Manual V1.00
Advanced Automotive M2MI/IoT Gateway
S2: System LED2 pattern overview (Cellular activity and "Wait For Event")
Pattern
Off
600 ms On / 600 ms Off green
75 ms On / 3 s Off green
75 ms On / 75 ms Off /
75 ms On / 3 s OFF green
Flashing green
On green (and all other LEDs OFF)
10 s OFF / 50 ms ON green
(and all other LEDs OFF)

Switches

DIP-switch

The RTCU NX-200 device contains two dip-switches. The dip switches are located on the front side
of the device for easy user access (see graphical overview).

System switch (RST)

The RTCU NX-200 device contains a combined reset/diagnostic switch. This switch is accessible
from the front of the unit (see graphical overview). It is necessary to use a small thin object with a
diameter of approx. 2 mm, for example, a straightened-out paper clip for this purpose.
By activating the switch shortly, the RTCU device will do a complete reset as if the power was
removed and reapplied.
If the reset switch is held down for approx. 3 seconds
where the application will not be started. In recovery mode, the system will automatically turn on
any communication channel and establish a connection to the RTCU Gateway (if configured).
Pressing reset will also activate the device when in power-down mode. If external power is
removed and the backup battery is disabled, the reset switch can still be used to boot into recovery
mode, as long as there is enough power left on the battery.
5 System LED S2 will flash green three times when this state is entered.
6 System LED S1 will indicates this state by fast blinking green or yellow.
Logic IO ApS.
Holmboes Allé 14
8700 Horsens
Denmark
Operating Status
The cellular engine is turned off
Missing SIM card or PIN code.
Network search and logon in progress.
Logged on to the network.
A Packet/GPRS session is active.
Indicates Packet/ GPRS data transfer.
The system is booting into recovery mode
The RTCU device is in low-power "Wait For Event" state.
the device will instead enter recovery mode
1
