RTCU NX-200 Technical Manual V1.00
Advanced Automotive M2MI/IoT Gateway

Product Identification Label with Barcode

The RTCU NX-200 product identification is found on the exterior of the device and contains a
unique serial-number in readable form and as a barcode.
The first three digits in the serial number identify the device type, and for the RTCU NX-200
device, this unique code is 321 or 322.
The barcode format used: 2/5 Interleaved with Check Digit

Power consumption

The table below shows detailed information about the typical power consumption for the RTCU
NX-200 device while it is running.
Power consumption: Device operating in normal mode
Device active
Device active with Cellular on LTE*
Device active with GPRS on LTE*
Device active with GNSS on
Device active with WLAN on
Device active with Ethernet on
Device active while charging
Note: Values marked with (*) is an average and should be considered as guidelines as they may
vary depending on the Cellular signal level.
Note: Power consumption was measured from a fully charged battery.
Logic IO ApS.
Holmboes Allé 14
8700 Horsens
Denmark
12V 24V BAT
85 35 225
110 55 300
300 150 700
100 45 280
100 55 305
100 45 310
600 300 -
Page 35 of 45
mA
mA Cell idle @ -65 dBm*
mA Cell @ -65 dBm.
Active communication.
Battery not charging*
mA Mode 4
mA Connected to AP, in idle
mA Connected to switch, in idle
mA
