Rtcu Nx-200 Specifications - Logic IO RTCU NX-200 Technical Manual

RTCU NX-200 Technical Manual V1.00
Advanced Automotive M2MI/IoT Gateway
RTCU NX-200 Specifications
RTCU M2M Platform
•
NX32L Execution Architecture.
•
Fully NX32 compatible.
•
Larger capacity and higher
performance compared to NX32.
•
Open and user-extendable API.
•
RTCU M2M Platform SDK.
NX32L Hardware Core
•
Cortex-A5 32-bit ARM processor.
•
Hardware floating point and DSP.
•
128 MByte LP-DDR RAM.
•
512 MByte NAND flash.
•
16 MByte NOR flash.
•
8 MByte Dataflash.
•
128 KByte SRAM with battery-backup.
•
Real-time clock with battery-backup.
Security
•
Embedded firewall.
•
TLS/SSL support with full certifcate
management.
•
TLS/SSL support for SMTP, MQTT, FTP,
HTTP, Gateway 2, and TCP/IP sockets.
•
Hardware assisted strong encryption/
authentication: AES-128, AES-192, AES
256, DES, TripleDES, HASH, RND, and
RSA signature.
Storage
•
Persistent data flash.
•
Non-volatile SRAM.
•
Internal flash drive (Up-to 512 MByte).
•
Circular datalogger.
•
SD-CARD.
•
USB flash media.
Logic IO ApS.
Holmboes Allé 14
8700 Horsens
Denmark
Cellular Engine
•
LTE Cat.4 Engine(World Wide).
Max 150 Mbps(DL)/Max 50 Mbps(UL).
LTE FDD: 15 bands.
LTE-TDD: 4 bands.
WCDMA: 7 bands.
GSM: Quad-band.
•
DTMF decoding / transmission.
•
Digitized voice playback / IVR.
•
Dual SIM card reader, with Mini-SIM
1.8/3 volt.
•
Application controlled SIM card.
•
Optional eSIM.
Wireless LAN
•
WiFi at 2,4 GHz ISM bands.
•
IEEE 801.11b/g/n/d/e/h/i.
•
WPA/WPA2 certification.
•
Up-to 150 Mbps.
GNSS
•
Multi-GNSS chip.
•
GPS, GLONASS and GALILEO.
•
99 acquisition / 33 tracking
channels.
•
SBAS (WAAS,EGNOS,MSAS,GAGAN).
•
A-GPS capable.
•
Anti-jamming, Noise cancellation.
•
Active 3 volt GNSS antenna.
•
Optional: Dead Reckoning.
Page 43 of 45
Bluetooth
•
Classic and Low Energy (LE).
•
Bluetooth 2.1 + EDR up-to 3 Mbps
•
Bluetooth 3.0 and 4.0 Dual mode.
•
Intelligent co-existence with WLAN.
Wired Communication
•
100BASE-T Ethernet interface.
•
2 x Full CAN2.0B with hardware
filtering and multi-speed support.
•
2 x RS232. One with control signals.
•
1 x RS485.
•
1-Wire bus.
•
2 x USB host port. One with lock.
•
USB service/programming port.
Audio
•
Fully digitized audio system.
•
Transfer, store and play audio.
•
Amplified speaker output.
•
Microphone input.
•
Digitized GSM audio.
User Interaction
•
4 x bi-colour LED.
•
DIP-switches.
•
Virtual jumpers for RS485 and CAN
termination.
•
CAN write enable jumper on one port.
•
Reset / recovery switch.
