Logic IO RTCU NX-200 Technical Manual page 13

RTCU NX-200 Technical Manual V1.00
Advanced Automotive M2MI/IoT Gateway
Connector X4: 6 pins COM2 connector overview
Pin Name
1 TD
2 CAN2-H
3 CAN2-L
4 RD
5 SGND
6 SGND
Connector X5: 6 pins FLXIN connector overview
Pin Name
1 FLXIN1
2 FLXIN3
3 AGND
4 FLXIN2
5 FLXIN4
6 AGND
Connector SER2: RJ45 connector overview, fully RS232 compatible
Pin Name
1 DSR
2 DCD
3 DTR
4 SGND
5 RD
6 TD
7 CTS
8 RTS
Logic IO ApS.
Holmboes Allé 14
8700 Horsens
Denmark
Description
Transmit Data from serial port 1, RS232 compatible
CAN-bus channel 2 H-signal
CAN-bus channel 2 L-signal
Receive Data for serial port 1, RS232 compatible
Signal Ground
Signal Ground
Description
Flex input 1
Flex input 3
Analog Ground
Flex input 2
Flex input 4
Analog Ground
Description
Data Set Ready
Data Carrier Detect
Data Terminal Ready
Signal Ground
Receive Data for serial port 2
Transmit Data from serial port 2
Clear To Send
Request To Send
Page 13 of 45
