Logic IO RTCU NX-200 Technical Manual page 8

RTCU NX-200 Technical Manual V1.00
Advanced Automotive M2MI/IoT Gateway
User Interaction:
➢ High-speed Mini-USB service-port connector.
Audio:
➢ Fully digitized audio system.
➢ Transfer, store, and play audio.
➢ Amplified speaker output.
➢ Microphone input.
➢ Digitized cellular audio.
➢ DTMF support for Interactive Voice Response applications.
Storage:
➢ Internal flash drive with up-to 512 MByte capacity.
➢ Persistent memory and circular datalogger.
➢ Standard SD-CARD reader.
➢
USB flash media.
Power and Battery:
➢ Operating voltage from 8 to 36VDC.
➢ Onboard 2.6 Ah Li-Ion battery with intelligent charging.
Encapsulation:
➢ Exclusive and durable aluminum encapsulation.
Regulatory Approvals:
➢ 2007/46/EC UN ECE R10 Rev. 05 (E1).
➢ 2014/53/EU Radio Equipment Directive.
➢ 2011/65/EU RoHS Directive.
