RTCU NX-200 Technical Manual V1.00
Advanced Automotive M2MI/IoT Gateway

99-channels multi-GNSS receiver

General:
Update Rate:
Accuracy:
Sensitivity:
Time-To-First-Fix :
2
Interface protocol:
1 Depends on accuracy of correction data provided by the SBAS service.
2 All satellites at -130 dBm.
3 Time to get a fix when signal has been blocked for a short period of time.
4 The GPS has been powered down for less than 2 hours and the stored position and time are valid.
5 The GPS has valid A-GPS information. A-GPS is currently unsupported in the standard firmware.
6 The GPS has been powered down for more than one hour, but has stored information about its current position and time.
7 The GPS has no valid navigation data.
Logic IO ApS.
Holmboes Allé 14
8700 Horsens
Denmark
MediaTek MT3333 Single Chip Super Sensitivity
99 acquisition / 33 tracking / up to 210 PRN channels.
Multi GNSS engine for GPS, GLONASS, GALILEO and QZSS
Support DGPS, SBAS (WAAS, EGNOS, MSAS, GAGAN).
A-GPS capable.
Anti-jamming, Multi-tone Active Interface Canceller.
NMEA @ up-to 4 Hz
Position
Velocity
DGPS/SBAS
Tracking/navigation
Reacquisition
Cold Start (Autonomous)
(GPS chipset reference parameters)
Autonomous Operation in Standard Sensitivity Mode
Reacquisition 3
Hot Start
4
Aided start
5
Warm start 6
Cold start 7
NMEA 0183 v3.01 with GGA, VTG, GLL, GSA, GSV and RMC.
Page 32 of 45
<2.5m CEP
<0.1m/s
<2.5m CEP 1
-165 dBm
-160 dBm
-148 dBm
< 1 sec.
< 1 sec.
< 3 sec.
< 30 sec.
< 35 sec.
