External connections

Overview

Connections to external equipment are made via the connectors that are located on the back and
front sides of the product.
The front panel is equipped with connectors commonly accessed by the user: SIM-Card, SD-Card,
DIP-Switches, audio input and output, LEDs, dual USB host ports, and USB slave service port.
The back panel holds all connectors necessary for installation: 4-pin (X1) power and ignition, 6-pin
(X4) for RS232 and CAN (channel 2), 12-pin (X2) for different communications interfaces, 16-pin
(X3) for analog and digital I/O, and 6-pin (X5) flex-inputs.
A graphical overview of the front- and back are shown below:
SIM card reader
SD card reader
GNSS
SER2
antenna
Pin 1
WLAN/BT
antenna
Logic IO ApS.
Holmboes Allé 14
8700 Horsens
Denmark
A
S1
DIP-Switch
1
B S2
SPKR
Front-side view
ETH
X5: FLXIN
1 1
4 7
Cell X4: COM2
antenna
Back-side view
Page 10 of 45
USB Host 1
USB Host 2
System
Locking
Tab
Switch
MIC
X3: I/O
4
1
1
3
X2: COM1
USB Service
9
1
X1: PWR
