RTCU LX5 eco Technical Manual V1.00
Advanced Industrial M2M/IoT Gateway

Technical Highlights

Platform:
➢ Based on the RTCU M2M Platform.
➢ NX32L (NX32 for Linux) execution architecture.
o
RTCU IDE development tool.
o
Operates under a full and highly optimized Linux variant.
o
Open and extendable with Platform SDK.
LX Hardware Core:
➢ Cortex-A7 32-bit ARM processor operating at up to 1 GHz.
➢ Cortex-M4 32-bit co-processor for advanced power-management.
➢ Hardware floating-point and DSP instructions.
➢ 128 MByte RAM.
➢ 512 MByte NAND Flash (system boot, persistent memory, and file-systems).
➢ Real-time clock.
Security:
➢
Embedded firewall.
➢
Port forward and NAT services.
➢
TLS/SSL support with full certificate management.
➢
TLS/SSL supporting all significant TCP protocols, such as RCH, FTP, SMTP, MQTT, and sockets.
➢ Hardware assisted encryption/authentication: AES-128, AES-192, AES-256, DES, TripleDES, HASH,
RND and RSA signature.
Wireless Communication:
➢ LTE Cat. 1 Multi-Band Cellular Engine.
➢ Internal SIM-card reader with support for eSIM.
➢ Medium range ISM band RF transceiver with an on-board antenna.
➢ Multi-constellation GNSS with GPS, GLONASS, and GALILEO.
Wired Communication:
➢ 1 x Full CAN 2.0B controller with hardware filtering and multi-speed support.
➢ 1-Wire bus for accessories such as ID-button reader, temperature sensors, etc.
➢ 1 x RS232 channel.
➢ 1 x RS485 channel.
I/O Interfaces:
➢ 3 x digital inputs.
➢ 2 x solid-state open-drain outputs.
➢ 3 x flex analog/digital inputs with 0..30 volt and 12 bit precision.
➢ Expandable I/O with standard Modbus modules.
Sensors:
➢ 3-axis Accelerometer with 16g scale.
➢ Temperature sensor.
User Interaction:
➢ 3 x bi-color LED.
➢ High-speed Mini-USB service-port connector.
