RTCU MX2 turbo Technical Manual V2.04

The technical highlights of the RTCU MX2 turbo:

➢ Based on the RTCU M2M Platform
➢ NX32 execution architecture.
➢ RTCU IDE development tool with a full featured device simulator.
o Huge standard API with more than 800+ functions.
o Comprehensive protocol support, including:
TCP-UDP/IP, FTP, SMTP, RACP, MQTT, MODBUS, FMS/J1939, NMP/Garmin FMI.
o Fully backward compatibility with existing X32 applications.
➢ 3G version: High-speed 3G/HSDPA GSM engine. Backward compatible with 2G/2.5G.
➢ 2G version: World-wide Quad-band GSM engine.
➢ Internal and external SIM-card reader selectable from the application.
➢ Digitized audio can be played over GSM or to an external device.
➢ DTMF support for implementation of Interactive Voice Response applications.
➢ State-of-the art Multi-GNSS positioning engine with GPS, GLONASS,QZSS.
➢ High-performance 3-axis accelerometer with 16g scale.
➢ Enhanced memory sub-system with fast program execution.
➢ Huge data-flash/logger memory with a capacity of 8.5 MB.
➢ Internal 8 MB FAT32 flash drive.
➢ Standard FAT32 SD-CARD reader with up to 32 GB capacity.
➢ 2 x RS232 channels and 1 x RS485 channel.
➢ 2 x analog inputs with 0..10 volt / 12 bit precision.
➢ 5 x digital inputs and 4 high-power solid-state digital outputs.
➢ Full CAN 2.0B controller with hardware filtering and multi-speed support.
➢ 1-Wire bus for accessories such as ID-button reader, temperature sensors, etc.
➢ Wide operating range from 8..36 VDC.
➢ External power can be selectable enabled/disabled by the application.
➢ On-board high-capacity Li-Ion battery.
➢ Advanced power-management with wake-up on a wide range of events.
➢ Hands-free interface with microphone and Class-D audio speaker amplifier.
➢ High-speed USB programming cable support.
➢ Fully supports the Professional Navigation and Messaging device PNM-220.
➢ Support the Garmin Fleet Management Interface.
➢ Fully supported by the RTCU Gateway 2 and the RTCU Deployment Server.
➢ Accessories: Wi-Fi, Ethernet, Bluetooth, Camera and PNM-220 Navigation Device.
➢ Exclusive and durable GOLD aluminum encapsulation.
1 Please see "The RTCU M2M Platform" data sheet for more information.
