Display

This section includes a power sense connection like those used on an MLA101 (used to
determine if the device is powered), a Pass-through for power sense, and and IR output
used to control the display.

Sources - IR

This section contains slots for connecting the IR emitter to the TH100; used to control
sources.

NetStreams IR Receiver

A connection for the NetStreams IR receiver. 3
use the IR block connection for 3

IR Block

If a third party IR distribution system is used, it would be connected here.

Contact Closures

Output relays can be set to normally open or closed, and triggered by a macro. Input
contact closures look for high/low and open/closed signals to trigger macros.

Power

Power connection for usage with any DigiLinX power supply.

Specifications

Audio Input Connectors
Control
IR (Reciever, Display, and Sources) 3.5mm to IR
RS-232 (Reciever Only)
IR Block Connection (output)
IR Block Connection (input)
Ethernet Connection
Power Sense (Reciever & Display) RCA
Contact Closures
1) Input
3) Output
IR Emitter
IR Receiver
Adhesive rubber feet
All specifications subject to change without notification. All rights reserved. Copyright © 2008 NetStreams
Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496
3600 W. Parmer Lane, Suite 100; Austin, TX 78727 /
rd
party IR recievers are not compatible,
rd
party IR systems.
Analog RCA (1 pair)
Stereo S/PDIF
3.5mm to DB9 (Female)
3 pin modular connector
3.5mm
RJ45
2 pin modular connector
2 pin modular connector
3 included
1 included
4 included
13-3
www.netstreams.com.
TheaterLinX
