DigiLinX Installation and Design Guide

Connecting Home Theater Audio

Requirements

How it Works

15-2
All specifications subject to change without notification. All rights reserved. Copyright © 2008 NetStreams
Using RCA cables, connect the left and right audio of the iPort wall plate to the left
2.
and right in ports on the MediaLinX.
Connect the RJ11 connector from the RS-232 port on the iPort wall plate.
3.
Connect the 3.5mm connector from the RS-232 port on the MediaLinX.
4.
Connect the male and female DB9 connectors on the loose ends of the cables in
5.
steps 3 and 4.
Every manufacturer's cable end is different. Therefore, you may need a gender
NOTE:
changer in step 5. However, do not use a null modem gender changer.
Connect power to the iPort wall plate.
6.
This section explains how to integrate home theater audio with a NetStreams DigiLinX
system.
speaker audio level switches as required
A/V receiver
sources
speakers
CAT5 cable with RJ45 connectors
RCA cables
speaker wire with four-pin Phoenix connectors
NetStreams AP300 Audio Port.
When voltage is sensed from the speaker wires of the output on the receiver, a relay is
switched over. This routes output to the speakers.
