DigiLinX Installation and Design Guide

Connectors

Installation

5-6
All specifications subject to change without notification. All rights reserved. Copyright © 2008 NetStreams
LEDs for signal detection, power detection, and activity status
Dimensions 17.25" wide x 1.75" high x 9.25" deep (438mm x 44mm x 235mm)
Weight 5.44 lb. (2.47 kg)
NetPower: 2
Five 3.5mm to RS-232 cables (included).
The MediaLinX Pro has the following connectors:
audio input connectors: four gold-plated RCA jacks
audio output connectors: four gold-plated RCA jacks, four coaxial digital (S/PDIF)
RJ45 connector
four power sensing RCA inputs
composite video passthrough
four 3.5mm IR emitter outputs/RS-232 outputs
four contact closures
doorbell mute interface.
The MediaLinX MLA4000 can be rack mounted or it can function as a standalone
device.

Installing a MediaLinX MLA4000 in a Rack

The MediaLinX MLA4000 can be mounted using rack ears. To install a MediaLinX
MLA4000, complete these steps:
Screw the rack mount ears into the MLA4000.
1.
Slide the MLA4000 into the rack.
2.
Screw the rack ears into the rack.
3.
For a MediaLinX:
Connect all legacy sources.
4.
Connect Ethernet.
5.
Connect power.
6.
For a ControLinX:
Configure the third-party system using the manufacturer's instructions.
7.
Connect the IR emitter or RS-232 connector to the third party device.
8.
Connect a 16/2 cable from the power port of the ControLinX to a PowerLinX.
9.
Connect a CAT5 Ethernet cable from the ControLinX to a SwitchLinX.
10.
