Introduction

This chapter covers pre-wiring for a DigiLinX audio and video network. DigiLinX
architecture is similar to the architecture used in computer networking. You require
devices, a network connection, and power.

Pre-Wiring for IP Audio

Requirements

Cables

The following cables are required to pre-wire for DigiLinX IP audio:
NOTE:
Siamese CAT5 16/4 (or CAT5 14/4) AWG cable
RG6 cable
CAT5e cable.

Terminating Wires

The following are required to terminate wires:
RJ45 crimpers
CAT5 stripper
wire cutters/strippers
small flat-head screw driver
RJ45 connectors
Phoenix connectors (for power and speaker connections). These are provided with
your NetStreams system.
All specifications subject to change without notification. All rights reserved. Copyright © 2008 NetStreams
Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496
Pre-Wiring for IP Audio and IP Video
When wiring for Ethernet, do not exceed 100 meter (328 foot) cable runs.
