ViewLinX
VL9100-CS
IP Multimedia Decoder
ViewLinX greatly simplifies the design and installation of large multi-zone audio/video distribution systems. HD and SD quality multimedia can
be distributed to virtually unlimited number of displays by placing a ViewLinX at each display, There is also no need to include separate
components for controlling the display, its all included in the ViewLinX. The DigiLinX system also contains control for sources and displays and
transports audio, video and control over one CAT5 with TCP/IP, meaning there is no need to wire a separate, expensive parallel infrastucture for
control.
Decentralized Network
Compressed or Uncompressed Video
Unlimited displays
SD/HD Video Decoder
ViewLinX DualDrive
Audio Decoder
Additional Features
Mounting Options
StreamNet™ Connected
and the processing power to be spread out across a TCP/IP network. This leverages many of the
advantages of using TCP/IP over traditional analog systems. Traditionally,a video signal is transmitted
over long cables runs that degrade the quality of the signal and can increase the project costs by
requiring multiple cable runs per display. Using a decentralized IP based system preserves the HD
quality of the signal and saves money by requiring only one CAT5 cable for audio,video,and control
of the display.
uncompressed form. Sending video uncompressed allows the HD quality to be preserved during
distribution on a gigabit network. However, not all installations have a gigabit network or need
uncompressed HD quality. For those projects the ViewLinX can be configured to use NetStreams
MotionXT
be re-configured to use uncompressed video.
number of displays obsolete. TCP/IP treats each ViewLinX as just another device on the network.
By using TCP/IP's multicast protocol DigiLinX easily manages the network traffic. NetStreams
StreamNet™ technology keeps each zone synchronized so that all zones play within 500
microseconds of each other, preventing an echo effect and keeping the audio and video in synch.
uncompressed) back into SD or HD content and then outputs it into the appropriate signal output
type. A ViewLinX can output H Sync,Vsync,Y/G/CVBS, Pb/B/C, and Pr/R signals through BNC
connectors and includes a HD 15 connector for VGA signals.
being used and route the signal to the appropriate connector. This is ideal for situations where a
display must display VGA and video signals. Dual Drive allows both BNC and DB-15 connectors to
be connected. The ViewLinX can also be programmed to switch the displays input based on the
source signal.
The Ultimate IP A/V Experience
Decentralized Architecture - DigiLinX uses a distributed architecture that allows the hardware
Compressed and Uncompressed Video - Video can be distributed in a compressed or
Video Compression. If at a later date,video quality needs change,the ViewLinX can
™
Unlimited Displays - Using TCP/IP as a distribution method also renders limitations on the
SD/HD Video Decoder - Each ViewLinX converts a DigiLinX IP stream (compressed or
DualDrive - ViewLinX DualDrive technology can automatically determine which signal type is
™
