13.

Pre-Wire for IP Video

Requirements

NOTE:
NetStreams IP video products at the display location.

Procedures

Figure 3-2 shows how to pre-wire for IP-Based video.
Figure 3-2
All specifications subject to change without notification. All rights reserved. Copyright © 2008 NetStreams
Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496
Repeat steps 1 through 8 for each pre-wired room.
one structured wire consisting of two twisted pair (CAT5e or better) cables and two
coaxial cables (RG6 or better)
one four-port flush mounted wall plate consisting of two RJ45 connectors and two
F connectors
one 16/4 DC power cable
You can also use a NetStreams local power supply such as a PL228 or PL250 to power
Pre-Wiring for IP-Based Video
3600 W. Parmer Lane, Suite 100; Austin, TX 78727 /
Pre-Wiring for IP Audio and IP Video
3-3
