DigiLinX Installation and Design Guide
Connectors
5-8
All specifications subject to change without notification. All rights reserved. Copyright © 2008 NetStreams
Real-time conversion of one component, composite, S-Video or VGA video signal,
and one stereo analog and digital S/PDIF audio signal from a video source into
TCP/IP uncompressed audio/video streams
480i format conversion across: Composite to S-Video, S-Video to Component or
vice versa
BURR-BROWN 24-bit/96KHz Analog-to-Digital converters
Power management sensor for Video, LED, or Level sensing of video sources for
audio playback
Integrated IR receiver
IR/RS-232 (two way) control of sources (cable included)
Includes three contact closures - two function as output contact closures and one
functions as a circuit closure detector
NTSC and PAL capable
LEDs for Signal detection, Power detection, and Activity status
Power State Sense Input
Dimensions: 9 1/2" high x 1 3/4" high x 8 2/3" deep (24mm x 45mm x 240mm)
Weight: 4 lbs (2.722 Kg)
NetPower: 4
ROHS compliant
Video Input/Output Connectors
Audio Input Connectors
Audio Output Connectors
Gigabit Ethernet Connection
2-position Phoenix Connector - power20 - 32VDC
IR Emitter output/RS232
IR Receiver input
3 Contact Closures
Main +1 512.977-9393 / fax +1 512.977.9398 / Toll Free Technical Support +1 866-353-3496
3600 W. Parmer Lane, Suite 100; Austin, TX 78727 /
Composite Input and pass-through (480i, 576i)
S-video Input and pass-through (480i, 576i)
Component Input and pass-through (480i, 480p,
720p, 1080i)
VGA Input (up to 1024 x 768 @ 60Hz)
One pair of analog RCA jacks (Gold Plated)
One Coaxial Digital (S/PDIF) (Gold Plated)
One pair of analog RCA jacks (Gold Plated)
One Coaxial Digital (S/PDIF) (Gold Plated)
RJ45
One 3.5mm
One included
One input, Two output
