8. Fix one A14 with two M3*40 Nylon Standoffs.
Assemble the following components
M3*8 Screw x1
M3*40 Nylon Standoff x1
9. Complete assembly of the clamp section.
Assemble the following components
A14 x1
M3*8 Screw x1
Effect diagram after assembling
Effect diagram after assembling
A14 x1
