ASSEMBLY AND INSTALLATION INSTRUCTIONS
CUBBY TOWER - 18" / 24" / 30"
1
A
Left Side Panel (Qty 1)
B
Right Side Panel (Qty 1)
C
Adjustable Shelf (Qty 2)
D
Set Shelf (Qty 2)
E
Rear Hanging Cleat (Qty 3)
A
TOOLS REQUIRED
(not included)
K
Level
L
Stud Finder
M
Drill, 3/32" bit size
N
Phillips Screwdriver
O
Screws, 3"
1.1
Lay parts out on a protective surface to prevent damage. Tip: Spread out the cardboard packaging to
use as a protective surface.
1.2
Inventory parts against the Parts List. Make sure all parts are present before proceeding.
PARTS LIST
B
K
N
F
Floor Support Panel (Qty 2)
G
Cam Post (Qty 18)
H
Camlock (Qty 19)
I
Shelf Pins (Qty 8)
J
Wood Dowels (Qty 4)
C
FINISHED EDGE
D
FINISHED EDGE
E
FINISHED EDGE
O
F
G
H
J
L
M
I
